The AZMJ filter capacitor is mainly cascaded with the low-voltage filter reactor to form the AC filter so as to provide the low-impedance channels for one or several kinds of filter currents to filter out the specified sub-harmonic currents, improve the functions of the system power factors. Its main characteristics are high-voltage resistant, low temperature rise, favorable capacity stability and long service life. It is the special capacitor for the power filtering device.
Executive standards: GB/T12747, IEC60831
1. Ambient Temperature: +55oC~-25oC
2. Altitude: Not higher than 3000m
3. Relative Humidity: 40oC≦50%；20oC≦90%
4. Environmental Conditions: no hazardous gases and vapors, no current-conducting and explosive dusts, no strenuous mechanical vibrations.
