TBBZ high-voltage parallel capacitor compensating complete device is mainly applied to the 6~35kV power supply system in generating plants, electric power bureaus, large factories and mining enterprises so as to regulate the voltage and reactive power according to the conditions of reactive power demands of the system and keep the voltage and reactive power within the set range, improve the grid quality and reduce the electric energy loss.
The indoor device adopts the cabinet structure and several cabinets are assembled in sequence. The outdoor device adopts the framework structure and the entire device periphery adopts the iron fence for isolation.
This device is based on the parallel capacitor and it is equipped with the single fuse protector for capacitor protection, discharging coil, ZnO arrester, series reactor as well as the bounce-free and re-strike-free vacuum contactor as the switching device.
This device meets the provisions in the related standards such as GB50227 Design Code for Parallel Capacitor, JB/T7111 High-voltage Parallel Capacitor Device, DL/T604 Technical Conditions for Order of High-voltage Parallel Capacitor Device.
